The barrier rings on the side fans have been slimmed down to allow for more lateral intake and to provide better airflow through the massive cooling array. The center fan’s extra blades and full-height ring provide boosted static pressure to blast air directly onto the GPU heat spreader. The ASUS Axial-tech fan design has matured with an increased blade count on all three fans: 13 on the center fan and 11 on the auxiliary fans.
This card has a dual (8+8) pin power header and the configuration is rated for up to 375 W of power draw. Better cooling and power limits mean that the GPU is able to sustain its boost clock speeds better, resulting in more performance.ĭisplay connectivity includes three standard DisplayPort 1.4 and one HDMI 2.1. The cooling solution is the ASUS DirectCU III, the latest in a long line of high-end air-based cooling solutions from ASUS that features an aluminum fin-stack heatsink and a trio of fans that turn off when the GPU is idling. The ASUS ROG STRIX RX 6700 XT OC features a custom-design PCB designed by ASUS with a massive 9+2 phase VRM that draws power from a pair of 8-pin PCIe power connectors, and several goodies, such as a digital RGB header, a couple of PWM case-fan headers, voltage measurement points for pro-users, and more. You also get extra rich feature: a blinding amount of RGB LED illumination, additional fan headers to let you synchronize your ventilation to the card, and an additional RGB out. It features a thick aluminum fin-stack heatsink that’s ventilated by trio of Axial-Tech fans with triple-fan cooling, this card is equipped with a dual-bios design with performance and silent mode the three fans start to spin and cool once the GPU warms up.
AMD attempted to overcome this by using the fastest standard GDDR6 memory chips that run at 16 Gbps and Infinity Cache, a fast on-die 96 MB cache memory that cushions data transfers between the GPU and memory. The increased 12 GB memory size over the past generation comes with a catch-the memory bus width is narrowed to 192-bit. The Navi 22 silicon at the heart of the RX 6700 XT physically features 40 RDNA2 compute units, which works out to 2,560 stream processors, 40 Ray Accelerators, 160 TMUs, and 64 ROPs.
GPU Z ROG EDITION SERIES
An interesting series of price adjustments and product launches ensures that even at its starting price of SGD$1399 – 3 Years limited warranty. The silicon also has a number of architectural changes. It’s based on the second “Navi” architecture that leverages the 7 nm silicon fabrication process. I have a nvme m.The ASUS ROG STRIX Radeon RX 6700 XT OC is AMD’s third true performance-segment graphics card in one years since the RX 5700 series. Right now in render test bus interface reads PCIe x16 3.0 3.0, The graphics card reports it supports PCI Express x16 v3 currently running PCI Express x2 v 1.1.
GPU Z ROG EDITION PC
Try the card in another compatible PC or take it to a PC repair shop for testing.The card may be faulty causing it to stay in X2 Mode.Hover your mouse pointer over the Bus Interface in GPU-Z and it will say what the graphics card reports that it supports. Try the card in the second PCIe x16 slot or try another card.
GPU Z ROG EDITION UPDATE
Update your motherboard to the latest BIOS (Version 1301) if needed. You want to run the Render Test in GPU-Z (the little "?" icon to the right of Bus Interface) to take the bus out of power saving mode. Bob16314 No way the Bus Interface should be in PCIe X2 Mode.Minimum it should be with the card in the PCIEX16/X8_1 slot is X8 Mode, if you have a card in the PCIEX8_2 slot.
